Viscosity Flow Cup Stand
- Stand suitable for use with Rhopoint DIN, ASTM, ISO and BS flow cups
- Supplied with a certificate of conformity
Flow Measurement
AFNOR Viscosity Flow Cup
- 2mm - 8mm orifice diameter
- 15 – 3000 cSt viscosity range
- 25 -150 sec flow times
- Supplied with a certificate of conformity
- Sheen 419/2.5, 419/4, 419/6 & 419/8 equivalent
ASTM D1200 Viscosity Flow Cup
- 2.1mm - 5.8mm orifice diameter
- 10 – 1200 cSt viscosity range
- 30-100 sec flow times
- Supplied with a certificate of conformity
- Sheen 406/1, 406/2, 406/3, 406/4 & 406/5 equivalent
BS3900 (1971) Viscosity Flow Cup
- 2.38mm - 7.14mm orifice diameter
- 38 – 1650 cSt viscosity range
- Flow times 300-300 sec
- Supplied with a certificate of conformity
- Sheen 401/2, 401/3, 401/4, 401/5 & 401/6 equivalent
DIN 53211 Viscosity Flow Cup
- 2mm - 8mm orifice diameter
- 15 – 3000 cSt viscosity range
- Supplied with a certificate of conformity
- Sheen 404/2, 404/4, 404/6 & 404/8 equivalent
ISO 2431 and ASTM D5125 Viscosity Flow Cup
- 3mm - 8mm orifice diameter
- 7 – 2000 cSt viscosity range
- 30 -100 sec flow times
- Supplied with a certificate of conformity
- Sheen 417/3, 417/4, 417/5, 417/6 & 417/8 equivalents
FRIKMAR Viscosity Flow Cup
- 2-8mm orifice diameter
- 15 – 3000 cSt viscosity range
- 25-150 sec flow times
- Supplied with a certificate of conformity
- Sheen 420/2, 420/4, 420/6 & 420/8 equivalents
